3050mm API 5L X70 WPHY70 Welded pipe fitting elbow

Short Description:

Name:Welded pipe fitting elbow
Standard: ANSI B16.9
Degree: 90 degree, 90d, 90 deg
Material: Carbon steel
Wall thickness :customized

Radius: LR(1.5D)

End: bevel end

Send email to us Download as PDF

Product Detail

Heat Treatment

Marking

Detailed Photos

Inspection

Packaging & Shipping

The common uses of pipe fittings

PRODUCT PARAMETERS

Product Name	Pipe elbow
Size	1/2"-36" seamless elbow(SMLS elbow), 26"-110" welded with seam. Biggest outside diameter can be 6000mm
Standard	ANSI B16.9, EN10253-2, DIN2605, GOST17375-2001, JIS B2313, MSS SP 75, etc.
Wall thickness	STD, XS, XXS, SCH20,SCH30,SCH40, SCH60, SCH80, SCH160, XXS and etc.
Degree	30° 45° 60° 90° 180°,etc
Radius	LR/long radius/R=1.5D,SR/Short radius/R=1D
End	Bevel end/BE/buttweld
Surface	nature color, varnished, black painting, anti-rust oil etc.
Material	Carbon steel: A234WPB, A420 WPL6 St37,St45, E24, A42CP, 16Mn, Q345, P245GH,P235GH, P265GH,P280GH, P295GH, P355GH etc.
	Pipeline steel: ASTM 860 WPHY42, WPHY52, WPHY60, WPHY65,WPHY70, WPHY80 and etc.
	Cr-Mo alloy steel: A234 WP11,WP22,WP5,WP9,WP91, 10CrMo9-10, 16Mo3 , 12crmov, etc.
Application	Petrochemical industry;aviation and aerospace industry;pharmaceutical industry,gas exhaust; power plant;ship building; water treatment, etc.
Advantages	ready stock,faster delivery time;available in all sizes,customized;high quality

PIPE FITTINGS

Butt welded pipe fittings includes steel pipe elbow, steel pipe tee, steel pipe reduer, steel pipe cap. All those butt welding pipe fittings, we can supply together, we have more 20 years production experiences.

If you are also interested other fittings, please click followed LINK to check details.

PIPE TEE PIPE REDUCER PIPE CAP PIPE BEND FORGED FITTINGS

WELD ELBOW

Welded fitting include elbow, tee, reducer, tee, cap, bend, stub end.

Regards to the welded fitting elbow, can be welded with single seam, two seams, more than two seams. That depend on how big size they are and what kind of price level you need.

While whatever which kind of seam you want, we done NDT test, 100% X-ray. We will supply rest report when delivery.

ELBOW SURFACE

Sand Blast

After hot forming, we arrange sand blast to make the surface to be clean and smooth.

After Sand blast, to avoid get rust, should do black painting or anti-rust oil, Hot dip galvanized (HDG) , epoxy, 3PE, vanished surface, etc. That is depend on customer's request.

DETAILED PHOTOS

1. Bevel end as per ANSI B16.25.

2. Sand blast first, then Perfect painting work. Also can be varnished.

3. Without lamination and cracks.

4. Without any weld repairs.

INSPECTION

1. Dimension measurements, all within standard tolerance.

2. Thickness tolerance:+/-12.5% , or on your request

3. PMI

4. MT, UT,X-ray test

5. Accept Third party inspection

6. Supply MTC, EN10204 3.1/3.2 certificate

PACKAGING& SHIPPING

1. Packed by plywood case or plywood pallet as per ISPM15

2. we will put packing list on each package

3. we will put shipping markings on each package. Markings words are on your request.

4. All wood package materials are fumigation free
